Elite Robots
CS620 is going to enrich Elite Robots' next generation of collaborative robots, the CS series.
The CS series is based on an advanced software infrastructure, with an intuitive and modular graphical user interface that supports the Python scripting language and self-developed plug-ins, offering a high level of customization for programmers. With 24 digital I/O (8 configurable) and 4 configurable tool I/O, and extensive connectivity options, it provides the highest expandability, while safety is ensured by compliance with ISO 10218-1 and ISO 13849-1 standards.
The CS series currently includes models with payloads of 3kg, 6kg, and 12kg, and CS620 further expands its already wide range of applications with a 20kg payload and 1,800mm reach. Combined with an industry-leading speed of up to 3.9m/s (that exceeds counterparts by up to 35%), it is perfect for effectively performing medium-to-high payload tasks such as handling heavy parts or palletizing, and meets the needs left unfulfilled by industrial robots.
Equipped with a dual tool connector (8-pin and 4-pin), the CS620 is the world's first cobot to supply end effectors through a 5A tool I/O. This ensures that the cobot always has enough power to perform demanding tasks, such as machine maintenance and welding, and to handle multiple devices simultaneously.
Like all other models in the CS series, the CS620 robotic arm features an IP65 degree of protection, upgradeable to IP68. The ISO class 5 cleanrooms also make the CS Series suitable for industries that require the highest level of hygiene, such as pharmaceutical and electronics.
