GKN Aerospace, teamed with Sikorsky Aircraft and the US Army's ManTech Program Office, has completed the design, development, and manufacture of the UH-60 Common Composite Tailcone (CTC) test units for BLACK HAWK helicopters. Long-term production potential of up to 1,000 tailcones over the next 20 years is possible.
The new all-composite tailcone has met critical goals in reduced weight, parts count, tooling costs, and manufacturing costs. The program has employed an improved manufacturing approach through the use of a Reduced Tooling Concept that has cut the number of tools by more than 70% over traditional methods while producing a highly repeatable, close tolerance structure. Costs have also been reduced through the use of automated fiber placement in the manufacture of the tailcone skins.
The CTC uses the advanced, lightweight material X-Cor throughout the details ofthe assembly. This is an engineered material that replaces traditional honeycomb in sandwich structures. The design also incorporates a paintless finish, which integrates the color into the skin laminate at the lay-up stage.
Jim Gibson, vice president, sales and marketing at GKN Aerospace, comments: "This pioneering program for the BLACK HAWK helicopter has employed a range of new techniques and materials, creating a valuable database of knowledge and understanding for all involved in the team. We believe this will support Sikorsky and the U.S. government as they bring the considerable benefits these technologies offer to other areas of the aircraft – and to other aircraft."
The GKN Aerospace facility in Tallassee, AL, led the manufacture of the six test units and was responsible for design producibility, production inputs, tool design and manufacture, process development, and hardware fabrication. They were supported by GKN Aerospace, St Louis, MO, where the CTC skin halves were fiber placed.
